ATV-50CC

QWATV-01C

ATV-50CC QWATV-01C

Model No.: QWATV-01C

* Headlight System!

* Triple Suspension System!
* Governor (Speed Limiter)
* Parking Brake
* Metal Chain Guard
* Off Road High Road Traction Knobby Tires
* Front Drum Brakes + Rear Hydraulic Brake!

Prev: Nothing

ATV-50CC QWATV-01C


ATV-50CC QWATV-01C


ATV-50CC QWATV-01C


ATV-50CC QWATV-01C


ATV-50CC QWATV-01C


ATV-50CC QWATV-01C


ATV-50CC QWATV-01C


Model

QWATV-01 C

Engine

50CC Air-cooled 4 Stroke, Single Cylinder

Starting Method

Electric

Ignition Mode

CDI

Fuel Tank Capacity

2.3L

Fuel

Straight Unleaded Petrol

Transmission

Automatic

Drive System

Chian

Throttle Control

Thumb throttle (screw restrictable to limit max throttle)

Suspension

Front : Dual A arm spring shocks
Rear : Large rear shock

Maximum Speed

65km/hr+

Front Brakes

Drilled disc hydraulics

Rear Brakes

Drilled disc hydraulics (controlled by left brake lever)

Maximum Load

100kg

Wheel Size

Front + Rear : 145/70-6 (both knobbed for all terrain use)

Rider Capacity

1 person

Dimensions (L x W x H)

BOX : 1070 x 640 x 580 (mm)
BIKE: 1200 x 670 x 800 (mm)
Seat Height : 570mm

Weight

Gross: 70kg
Net: 62kg

Container Loading

72 PCS(20GP); 152 PCS(40HQ)
